Audiolab Omnia - A Hi-Fi Integrated Amp, and then some
The Audiolab Omnia is an ultra-flexible all-in-one amp that features an on-board CD player, dedicated phono input and multiple digital and analogue input options plus with DTS Play-Fi built-in its networking features mean it can be part of a multi-room streaming audio system, so you can fill your house with music.
With Omnia just add a nice pair of speakers and some decent speaker wire and you have a top-notch Hi-Fi system ready to play your CDs and streaming music — and grow with you.
Fundamental power
A beefy toroidal transformer lies at the heart of the Omnia’s discrete Class AB circuitry. It gives you 50 watts per channel of strong, clean, nimble power. And it's 4-ohm stable, which means you can use it with a wide range of speakers.
A built-in dedicated headphone amplifier with a front-panel jack lets you plug in your favourite set of headphones for unobtrusive private listening.
On-board network streaming
The Audiolab Omnia uses DTS Play-Fi® to bring all your streaming sources together in one simple app for Apple® and Android™ devices. That means you can add other Play-Fi enabled components to your streaming network and control them all as one. Play the same music everywhere or pick different songs for any room you choose. This amp is also Roon certified which gives you another way to control the music in multiple rooms with Roon’s powerful software.
Spin your CDs
The Omnia's built-in CD player is based on Audiolab's highly regarded 6000CDT disc transport. The player features a read-ahead digital buffer that reduces disc-reading failures and may even allow you to play slightly damaged CDs.
Wirelessly connect via Bluetooth
For the most convenient access to wireless music playback, Omnia offers Bluetooth connectivity with high-quality, low latency thanks to the latest Bluetooth v5.0 aptX standard
Flexible connections and configurations
Five analogue stereo RCA inputs let you connect anything from a turntable to a tape deck, and even an outboard preamp. Two optical and two coaxial digital inputs give you the option to use the Omnia's high-performance internal DAC with any component that has a digital output, so you could connect your TV for great-sounding stereo playback. It also has a preamp output that lets you bypass the internal amplifier giving a simple future upgrade path.
If you're into super-high-resolution audio files, connect your computer to the Type-B USB input. The built-in 32-bit DAC can decode PCM up to 768kHz, DSD512, and MQA files
Specifications
Specifications
Audiolab Omnia Specifications
|
General Description |
Integrated Amplifier |
|
|
Design Philosophy and Core Technology |
2x50W (8ohm) / 2x75W (4ohm) Class AB |
|
|
ES9038Q2M 32-bit DAC |
||
|
- 4.3" (800x480mm) large size full view IPS LCD |
||
|
Built in certified hardware MQA Full decoder (PC USB, Coax/Optical) |
||
|
CD playback compatible with CD, CD-R, CD-RW discs |
||
|
USB memory device support (MP3/WMA/AAC/WAV) |
||
|
DTS Play-Fi technology (IEEE 802.11 a/b/g/n/ac) |
||
|
Streaming service support includes Amazon Music, Spotify, TIDAL, KKBox, SiriusXM, Napster, Internet Radio, Deezer, iHeartRadio, PANDORA, Qobuz, QQmusic and more |
||
|
Multi-room / multi speaker group support |
||
|
Bluetooth 5.0 (aptX/aptX LL) streaming |
||
|
Low Noise Moving Magnet Phono stage |
||
|
Dedicated Current-Feedback Headphone AMP |
||
|
Integrated / PRE-POWER / PRE only Modes |
||
|
Android / iOS / Kindle Fire / Windows PC Control Support |
||
|
USB firmware upgrade input |
||
|
Inputs |
3 x Analogue, 1 x Phono (MM) , 1 x Power Amplifier, 2 x SPDIF (Coax), |
|
|
2 x SPDIF (Optical), 1 x DTS Play-Fi Streaming, 1xPC USB(USB B), |
||
|
1xUSB HDD(USB A), 1 x Bluetooth(aptX/aptX LL), 1 x 12V Trigger |
||
|
Outputs |
1 x PRE Amplifier, 1 x Stereo Speaker, 1 x Headphone, 1 x 12V Trigger |
|
|
Sampling Frequency |
Optical / Coaxial:44.1kHz ---192kHz |
|
|
Optical / Coaxial: 44.1kHz ---192kHz |
||
|
Preamplifier Section |
||
|
Gain |
+8dB (Line) |
|
|
+47dB (Phono MM) |
||
|
Input Sensitivity |
720mV (Line, Volume = 0dB) |
|
|
3.1mV (Phone MM, Volume=0dB) |
||
|
Input Impedance |
10K (Line) |
|
|
47K // 100pF (Phono MM) |
||
|
Total Harmonic Distortion (THD) |
< 0.0004% (1KHz @ 2V, Volume = 0dB) |
|
|
Frequency Response |
20Hz-20kHz (+/-0.1dB) |
|
|
Output Voltage |
2.3V max. (Volume = 0dB) |
|
|
Output Impedance |
100 ohm |
|
|
Signal-to-Noise Ratio |
>110dB (Line,A-weighted) |
|
|
76dB (Phono MM,A-weighted) |
||
|
DAC |
||
|
D to A Converte |
ES9038Q2M |
|
|
Total Harmonic Distortion (THD) |
< 0.0006% (1KHz @ 0dBFS) |
|
|
Output level (0dBFS, 1KHz) |
2.1Vrms |
|
|
Max. Sampling Frequency |
Optical, Coaxial: 192KHz |
|
|
Ethernet,Wi-Fi: 192KHz |
||
|
USB A：48kHz |
||
|
PC USB: PCM768kHz, DSD512 |
||
|
Signal-to-noise Ratio (S/N) |
114dB (A-weighted) |
|
|
Power Amplifier Section |
||
|
Gain |
+29dB |
|
|
Rated Power Output |
2 x 50W (8 ohm, THD < 1%) |
|
|
2 x 75W (4 ohm, THD < 1%) |
||
|
Frequency Response |
20Hz-20kHz (+/-0.3dB) |
|
|
Total Harmonic Distortion (THD) |
< 0.003% (1kHz @ 40W / 8ohm) |
|
|
Input Sensitivity |
720mV |
|
|
Signal-to-Noise Ratio (S/N) |
110dB (A - weighted) |
|
|
Max. Output Current |
9A |
|
|
Headphone Amplifier |
||
|
Total Harmonic Distortion (THD) |
< 0.01% (1kHz, 50mW ) |
|
|
Output Impedance |
10ohm |
|
|
Load impedance |
20-600 ohm |
|
|
General |
||
|
Standby Power Consumption |
< 0.5W |
|
|
Net Weight |
9.1kg |
|
|
Gross Weight |
11kg |
|
|
Dimensions (mm) (W x H x D) |
440 x156 x 327 |
|
|
Carton Size (mm) (W x H x D) |
540 x 412 x 210 |
|
|
Finish |
Black / Silver |
|
|
Power Requirements (depending on region) |
220-240V ~ 50/ 60Hz |
|
|
100-120V ~ 50/ 60Hz |
||
|
Standard Accessories |
Power Cord, Remote Control,User Manual, Antennas, etc. |
