Rotel DX-5 Integrated Stereo Amplifier with DAC & Headphone Output
The Rotel DX-5 is a compact, high-performance integrated stereo amplifier designed to deliver refined sound and modern flexibility in a single, elegant component. Combining premium Class AB amplification, aptX HD Bluetooth wireless streaming, a high-quality built-in DAC and a dedicated headphone output, the DX-5 is the perfect choice for those wanting a high performance, versatile amplifier that looks stylish and doesn’t require too much space.
At its core, the DX-5 features carefully engineered amplification that delivers clean, dynamic power with excellent control and musicality. Whether driving bookshelf or floorstanding loudspeakers, it offers a balanced, engaging sound signature that remains detailed and composed across the frequency range.
The integrated DAC supports high-resolution digital audio and allows direct connection to computers, streamers, CD transports, and TVs, ensuring accurate digital-to-analogue conversion with low noise and precise timing. For personal listening, the front-panel headphone output is driven by a dedicated amplification stage, capable of powering a wide range of headphones with clarity and authority.
Housed in a solid, space-efficient aluminium chassis, the DX-5 reflects Rotel’s minimalist industrial design and long-standing commitment to build quality. Intuitive front-panel controls, a clear display, and versatile rear-panel connectivity make it easy to integrate into both modern and traditional audio setups.
Compact yet capable, the Rotel DX-5 is an ideal all-in-one solution for music lovers seeking premium stereo amplification, high-quality digital playback, and headphone listening in a single refined unit.
Specifications
Specifications
|
Model |
DX-5 |
|
Continuous Power Output |
33 W / ch, (1k Hz, 4 Ω) 25 W / ch (1k Hz, 8 Ω) |
|
Total Harmonic Distortion (THD) |
< 0.03% |
|
Intermodulation Distortion (60Hz:7kHz, 4:1) |
< 0.03% |
|
Frequency Response |
Digital section 10 Hz – 80k Hz (0 ± 2 dB, Max) Analogue section 10 Hz – 100k Hz (0 ± 0.19 dB) |
|
Damping factor |
140 |
|
Input Sensitivity / Impedance |
Digital section -10.3 dBFS / 75 Ω Analogue section 680 mV / 100k Ω |
|
Input Overload |
Analogue section 4.2 V |
|
Signal to Noise Ratio > 100 dB (IHF “A” weighted) |
1.2V |
|
Tone Controls - Bass / Treble |
±10 dB at 100Hz / 10kHz |
|
Signal to Noise Ratio (IHF “A” weighted) |
Digital section > 100 dB Analogue section > 100 dB |
|
Digital Inputs |
SPDIF LPCM (up to 24-bit / 192k Hz ) |
|
PC-USB |
USB Audio Class 2.0 (up to 32-bit / 384k Hz )* *Driver installation required Support DSD (up to 4X, 11.2M Hz) and DoP (up to 2X, 5.6M Hz) |
|
Roon tested |
Yes |
|
HDMI |
Support ARC function |
|
General |
- |
|
Power Requirements (AC) |
230V, 50Hz (Europe) |
|
Power Consumption |
80Watts |
|
Standby Power Consumption 0.5W |
<0.5Watts |
|
Dimensions (W x H x D) |
215 x 76 x 251 mm |
|
Panel Height |
70mm |
|
Weight (Net) |
4.1 kg |
|
Finishes |
Black, Silver |
